Entratech Product Listing (Contact us for Volume & OEM Pricing)

Signal Filters™ Products - Filter division of Entratech Systems Signal Filters™ Products can be purchased directly from their Online Store, or are available at Dealers, Distributors and OEM’s. For a full list of where to buy, go to the Signal Filters website.

SignalFilters.com

SENSOR KIT: Glass Filled Nylon WIF Bowl Mount Sensor with LED indicator and harness Rugged water-in-fuel probe designed with internal circuit board to detect water contamination at a predetermined level. On board anti slosh and a unique (patent pending) probe current shut off circuitry provide long service life even when water is sensed and not drained for extended times. Includes Imbedded LED indicator light driver circuit interface to warn when water-in-fuel is detected. Can be used in any robust off-road, on-road vehicle, marine or generator set application. #KIT ENS-GF-L3 INCLUDES:

• Glass Filled Nylon WIF Bowl Mount Sensor with Packard 3-terminal connector
• LED Indicator light to detect water-in-fuel
• 6 Ft high-quality wire harness with connector
• 12/24 VDC

CHOOSE SENSOR STYLE: 1/2 - 20 straight thread with O-ring sealing design (RACOR style)
or
M14 x 2 metric thread with O-ring sealing design (FLEET GUARD style)

Stainless Steel WIF Sensor (single probe, 1/2 x 20 thread) Rugged water-in-fuel probe available with or without internal EOL (End Of Line) resistors engineered to interface with Engine Control Module (ECM). For use in marine machinery spaces that must conform to ABS marine standards when mated to an ABS approved filter. Can be used in any robust off-road, on-road vehicle, marine or generator set application. #110006AA: passive (Racor style)
Use with #110005AA 2-Wire Harness-Green/Black

• Meets requirements of ISO19921 and ABS marine standards when mated to an ABS approved filter
• Designed to UL Separator standards
• Stainless steel and ceramic construction
• SAEJ1926 straight thread with O-ring sealing design
• Packard GT-Series 2-terminal connector

Stainless Steel WIF Sensor (1/2 x 20 thread) Rugged water-in-fuel probe designed with or without internal EOL (End Of Line) resistor value per manufacturers requirements to interface with Engine Control Modules (ECM). Can be used in any robust off-road or on-road vehicle, marine or generator set application. #WW004841AA: passive
#WW004811AA: 82.5K Ω (Cummins style)
#WW004821AA: 220K Ω (JD ECM style)
Use with #110026AA 2-Wire Harness

• 1/2 - 20 straight thread with O-ring sealing design (RACOR style)
• Ampseal 16 DELPHI-Series 2-terminal connector

Stainless Steel WIF Sensor (M14 x 2.0 thread) Rugged water-in-fuel probe designed with or without internal EOL (End Of Line) resistor value per manufacturers requirements to interface with Engine Control Modules (ECM). Can be used in any robust off-road or on-road vehicle, marine or generator set application. #WW004842AA: passive
#WW004812AA: 82.5K Ω (Cummins style)
#WW004822AA: 220K Ω (JD ECM style)
Use with #110026AA 2-Wire Harness

• M14 x 2.0 thread with O-ring sealing design (FLEET GUARD style)
• Ampseal 16 DELPHI-Series 2-terminal connector

Glass Filled Nylon WIF Bowl Mount Sensor (1/2 x 20 thread) Rugged water-in-fuel probe designed with internal circuit board to detect water contamination at a predetermined level. On board anti slosh and a unique (patent pending) probe current shut off circuitry provide long service life even when water is sensed and not drained for extended times. Can be used in any robust off-road, on-road vehicle, marine or generator set application.
(Not fit to accommodate Racor turbine series filter bowls) #WW003801AA: passive
Use with Entratech 3-Wire Harness, and Entratech Indicator Lamp

• 1/2 - 20 straight thread with O-ring sealing design (RACOR style)
• Packard GT-Series 3-terminal connector
• 12/24 VDC

Glass Filled Nylon WIF Bowl Mount Sensor (M14 x 2.0 thread) Rugged water-in-fuel probe designed with internal circuit board to detect water contamination at a predetermined level. On board anti slosh and a unique (patent pending) probe current shut off circuitry provide long service life even when water is sensed and not drained for extended times. Can be used in any robust off-road, on-road vehicle, marine or generator set application.
(Not fit to accommodate Racor turbine series filter bowls) #WW003802AA: passive
Use with Entratech 3-Wire Harness, and Entratech Indicator Lamp

• M14 x 2 metric thread with O-ring sealing design (FLEET GUARD style)
• Packard GT-Series 3-terminal connector
• 12/24 VDC

Glass Filled Nylon WIF Sensor (1/2 x 20 thread) Rugged water-in-fuel probe designed with or without internal EOL (End Of Line) resistor value per manufacturers requirements to interface with Engine Control Modules (ECM). Can be used in any robust off-road or on-road vehicle, marine or generator set application. #WW002841AA: passive
#WW002811AA: 82.5K Ω (Cummins style)
#WW002821AA: 220K Ω (JD ECM style)
Plastic probes require the #110014AA 2-Wire Mating Harness to hook up.

• 1/2 - 20 straight thread with O-ring sealing design (RACOR style)
• Ampseal 16 TE-Series 2-terminal connector

Glass Filled Nylon WIF Sensor (M14 x 2.0 thread) Rugged water-in-fuel probe designed with or without internal EOL (End Of Line) resistor value per manufacturers requirements to interface with Engine Control Modules (ECM). Can be used in any robust off-road or on-road vehicle, marine or generator set application. #WW002842AA: passive
#WW002812AA: 82.5K Ω
#WW002822AA: 220K Ω
Plastic probes require the #110014AA 2-Wire Mating Harness to hook up.

• M14 X 2 metric thread with O-ring sealing design (FLEET GUARD style)
• Ampseal 16 TE-Series 2-terminal connector

Low Coolant Sensor (12/24V) Standard Tank Mount Coolant Level Sensors can be interfaced to engine computers. Tank mount design with conductive fluid sensing circuit, has a time delay to prevent false alarms from coolant sloshing. #LCS-ISE-12/24
Use with #W003813AA 3-Wire Harness

• 12-24 VDC operation
• Power on self-test
• Grounds up to one amp resistive or inductive load
• Unique non-plating sensing technology
• Long life stainless steel probe tip

2-Wire Harness (TE connector) High-quality wire harness with TE connector. #110014AA

• Compatible with Entratech WW002800-series Nylon WIF sensors.
• 6 ft. Harness

2-Wire Harness (DELPHI connector) High-quality wire harness with DELPHI connector. #110026AA

• Compatible with Entratech WW004800-series Stainless Steel WIF sensors.
• Replacement sensor harness for Signal Filters^™ KIT SFH-SS-G1 and KIT SFH-SS-G2
• 6 ft. Harness

2-Wire Harness-Green/Black (DELPHI connector) High-quality wire harness with DELPHI connector. #110005AA

• Compatible with Entratech WW0006AA Stainless Steel WIF sensors.
• Replacement sensor harness for Signal Filters^™ KIT SFH-SS-G1 and KIT SFH-SS-G2
• 6 ft. Harness - Green/Black

4-Wire Harness High-quality wire harness with connector. #W004812AA

• Compatible with Entratech Indicator Gauges
• 6 ft. Harness

3-Wire Harness High-quality wire harness with connector. #W003812AA

• Use with Signal Filters^™ KIT SFH-SS-L3
• Compatible with Entratech 3-wire WIF sensors
• 6 ft. Harness

3-Wire Harness (for Coolant Sensor) High-quality wire harness with connector. #W003813AA

• Compatible with Entratech Coolant Sensor
• 6 ft. Harness

Water-in-Fuel Indicator Gauge Gauge has indicator light to warn when water-in-fuel is detected. #110018AA

• Use with Signal Filters^™ KIT SFH-SS-G1
• For 1 filter
• 12/24V DC, Black Bezel
• 3 ft. Harness

Water-in-Fuel Dual Indicator Gauge Dual Gauge has 2 indicator lights to warn when water-in-fuel is detected. #110019AA

• Use with Signal Filters^™ KIT SFH-SS-G2
• For 2 filters
• 12/24V DC, Black Bezel
• 3 ft. Harness

Water-in-Fuel Indicator Lamp Indicator light to warn when water-in-fuel is detected.

• Use with Signal Filters KIT SFH-SS-L3
• For 1 filter
• Imbedded indicator light driver circuit interface

LED Indicator Module Multi-use LED Indicator light.
#110022AA: 24V
#110023AA: 12V

• 1 LED indicator light
• 5-wire

M670C-J Marine Fuel/Drain Valve Drain valve can be used with Signal Filters 8" Filter.

• UL approved for motor craft fuel line/drain
• Internal 90° turn stop mechanism for open and close
• Corrosion proof internal construction
• 1/4" Diameter port hole
• 1/8" NPT pipe thread on both ends

Water-in-Fuel Audible Indicator Audible indicator produces an audible warning sound, when water-in-fuel is detected.

• Use as replacement for Signal Filters LED indicator
• Loudness: 68dB@ 2' at 6Vdc up to 80dB @ 2' at 28Vdc
• Mode: Medium, Slow Pulse @ 0.5 - 2.5 PPS
• Panel screw terminals
